TekBox TBWA2/20dB

Low-distortion 20 dB preamplifier, ideal for use with near-field probes. These amplifiers produce significantly less non-linear distortion than the spectrum analyzers built-in preamplifier.

2 years warranty

₹34,690.00 ₹27,990.00

In Stock 2-3 Weeks

In Stock 2-3 Weeks

Share (0)
Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0

Description

  • Frequency range: 3 MHz..6 GHz
  • Gain: typ. 20 dB
  • Maximum input power: +10 dBm
  • Maximum output power: +20 dBm (100 mW)
  • IP3 (OIP3): +35 dBm
  • Noise: typ. 4.5..5 dB (@ 2 GHz)
  • Input + Output: SMA connectors (female)
  • Power supply: 5 V, 100 mA (Mini-USB-B)

Downloads

Datasheet

TBWA2-Datasheet

Language: English
File Size: 364.68 KiB
Release Date: 27.12.2018
