Rigol DG952

Code: DG952

High quality two channel function / arbitrary waveform generator with 50 MHz bandwidth, 250 MSa/s and 16 Mpts memory.

3 years warranty

₹84,205.00 ₹78,942.00

In Stock 2-3 Weeks

In Stock 2-3 Weeks

Share (0)
Total: 0 Total: 0 Total: 0 Total: 0 Total: 0 Total: 0

Description

Engineers and students who require high signal fidelity in a reliable and capable waveform generation need look no further than the DG952 Series generators. With frequencies up to 50 MHz, 16Bit Resolution, and arbitrary waveforms of up to 16 Mpts the DG952 reproduces any waveform with high signal fidelity. SiFi II adds additional filtering capabilities making this one of the most flexible generators on the market.
The intuitive touchscreen control and compact fanless design make it the perfect choice for your desk, bench, or lab.

Model DG952 DG972 DG992
Max. Frequency 50 MHz 70 MHz 100 MHz
Resolution 1 µHz 1 µHz 1 µHz
Sample rate 250 MSa/s 250 MSa/s 250 MSa/s
vertical resolution 16 bits 16 bits 16 bits
Max Amplitude 2.5 Vpp < 60 MHz 1 Vpp < 60 MHz 1 Vpp < 60 MHz
Frequency Counter up to 240 MHz up to 240 MHz up to 240 MHz
Channels 2 2 2

SPECIFICATIONS

SPECIFICATIONS
Generator Function / Waveform Generator Rigol DG952
Display 10.22 cm (4.3″) TFT LCD Intuitive Touch Screen design
Interfaces USB-Host (for USB stick i.e. to save/load waveforms)
USB-Device for a PC connection
USB-GPIB
Dimensions
237.4 mm × 97 mm × 268 mm
Weight 2.85 kg
Function Function / Waveform Generator Rigol DG952
Channels 2
Signal Output Sine, Square, Ramp, Pulse, Noise, DC, Dual-tone
PRBS, RS232, Sequence,160 types of waveforms, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine,
Lorentz, etc
Vertical Resolution 16 bit
Amplitudes ≤10 MHz: 1.0 mVpp to 10 Vpp
≤30 MHz: 1.0 mVpp to 5.0 Vpp
≤60 MHz: 1.0 mVpp to 2.5 Vpp
DC Offset ±5 V (50 Ω)
Sample Rate 250 MSa/s
Frequency Range Sine 1 μHz to 50 MHz
Frequency Range Square 1 μHz to 15 MHz
Frequency Range Pulse 1 μHz to 15 MHz
Frequency Range Ramp 1 μHz to 1.5 MHz
Frequency Range Harmonics 1 µHz – 20 MHz
Frequency Range Arbitrary 1 µHz – 20 MHz
Frequency Range Noise 100 MHz (-3db)
PRBS 2 kbps to 40 Mbps
Resolution 1 µHz

Downloads

Datasheet

DG900 Data sheet

Language: English
File Size: 4.37 MiB
Release Date: 27.12.2018

Manual

DG900 Manual

Language: English
File Size: 1.71 MiB
Release Date: 27.12.2018

DG900 Quick Guide

Language: English
File Size: 2.31 MiB
Release Date: 27.12.2018
