GW Instek GPT-12002 AC/DC Electrical Safety Analyzer

Description

GW Instek GPT-12002 is a IEC 61010-2-034 compliant Electrical Safety Analyzer with 200VA output capacity.

Providing the markets with safe electronic products is the responsibility of every manufacturer! Similarly, safety analyzer that tests whether electronic products meet safety regulations must attach the importance to the safety it provides! GW Instek GPT-12000 is the world’s first safety analyzer to comply with IEC 61010-2-034 (Safety requirement for electrical requirement for measurement, control and laboratory use – particular requirements for measurement equipment for insulation resistance and test equipment for electric strength). Apart from this, the safety considerations also include double insulation for input and output voltages, safe output/warning mechanism, post-test discharge mechanism, etc. to ensure user safety during the operation.

GW Instek GPT-12002 performs:

• AC Withstanding up to 5kV
• DC Withstanding up to 6kV
• Continuity Test up to 90Ohm with output current fixed at 100mA (dc)

GW Instek GPT-12002 Included Accessories:

• 1 x Quick Start Guide
• 1 x CD (completed user manual)
• 1 x Power cord
• 1 x Interlock key
• 1 x GHT-119 Remote terminal Cable
• 1 x GHT-115 Test lead

GW Instek GPT-12002 Key Features:

• 200VA AC Test Capacity
• Comply with IEC 61010-2-034
• 7” TFT LCD
• Manual / Auto Mode
• True RMS Current Measurement
• Zero Crossing Turn-on Operation
• Controllable Ramp-up & Ramp-down Time
• Capacitive Load Testing Capability up to 47μF
• Statistics Function
• Sweep Function for DUT Characteristic Analysis
• USB Storage available
• Rear panel output available
• Interface: RS-232C, USB host/device, Signal I/O and GPIB (optional)
• Universal power input
