4~8 inch entry level probe station. Highly cost-effective for tests and measurement requirements of I-V/CV, RF tests, etc.

SimplePS probe stations can meet your urgent needs of probe staitons. We can ship to you within ONE week for standard SimplePS systems.

The most common set up for SimplePS probe station systems are:

1. Basic I-V tests: SimplePS Probe Station, DTP100 Micropostioner, S10 Series probe holders.

2. Precision I-V/C-V tests: SimplePS Probe Station, DTP100 Micropostioner, CPA-10 coax probe, FP-A100 probe adapter, MiniShield shield enclosure.

3. RF tests: SimplePS Probe Station, DCP100 Micropostioner, M40A RF probe, RFH100 probe adapter.

Users can also choose from our various accessories such as cameras, vacuum pumps, cable assemblies, adapters, etc.

4~12 inch set ups. Modular design, highly cost-effective and can be upgraded as your requirements changes.

In order to acquire accurate and reliable test results in the cutting edge tests, one of the key factors is to use a probe station system with ultra mechanical accuracy and stability.

HAPS is built on a granite base with less than 5 micron planarity. This design not only assures the high planarity in X-Y motion but also provides a rigid and stable platform for high accuracy tests. To achieve positioning accuracy, we use precise micrometer heads to drive spring loaded X-Y axes. With an air bearing X-Y stage, user will be able to move the X-Y in coarse positioning smoothly and quickly, thus greatly reducing set up time and improving test efficiency. One of the most common applications of HAPS is millimeter wave device characterization. The accuracy and stability act as an important role in protection of fragile and expensive mmW probes while producing reliable test results.
